GrowFAQ Electrical Safety Hazard Warning, The Physical Effects of Electricity
Added by: 10k Last edited by: administrator Viewed: 462 times
Rated by 6 users: 10.00/10
Contributed by: Tommy Submitted September 9, 2003
The Physical Effects of Electricity : Electrocution or electrical shock occurs when an electric current I passes through the body. The amount of current passing through the body is determined by Ohm’s Law:
I = E/R
I = Current Through the Body E = Voltage across the body R = Resistance of the Body
Body resistance is an important variable when considering electrocution. There is a wide variation in body resistance between people therefore the same voltage level may result in different effects. The typical human body has a hand to hand resistance (R) somewhere between 1,000 and 2,000 ohms. Babies, Children and some other people have less resistance.
The current is the controlling factor for Electrocution and Electrical Shock. The threshold for perception is about 100 microamps (0.0001 Amps). Also See Microshock Electrocution Hazards for currents less than 100 microamps. The National Electrical Code (NEC) considers 5 milliamps (0.005 Amps) to be a safe upper limit for children and adults hence the 5 milliamps GFI circuit breaker requirement for wet locations. The normal nervous system reaction to any perceptible electrical shock may cause a person to injure themselves or others, therefore the so called safe limit does not assure freedom from injury.
The more serious electrocution and shock hazards occur above the let go limits. 99% of the female population have an let go limit above 6 milliamps, with an average of 10.5 milliamps. 99% of the male population have an let go limit above 9 milliamps, with an average of 15.5 milliamps. Prolonged exposure to 60 Hz. currents greater than 18 milliamps, across the chest causes the diaphragm to contract which prevents breathing and causes the victim to suffocate. No data is available for females or children but suffocation is presumed to occur at a lower current level.
The frequency of the electrical current is as important as magnitude when evaluating electrocution and electrical shock injuries. Humans and animals are most susceptible to frequencies at 50 to 60 hertz. The internal frequency of the nerve signals controlling the heart is approximately 60 hertz. Ventricular fibrillation occurs when 60 hertz current from the electric shock interferes with the natural rhythm of the heart. The heart loses its ability to pump and death quickly follows. Ventricular fibrillation can occur at current levels as low as 30 milliamps for a two year old child and 60 milliamps for adults. Most adults will go into ventricular fibrillation at hand to hand currents below 100 milliamps (0.1 Amp).
Humans are able to withstand 10 times more current at DC and at 1000 hertz than at 50 or 60 Hz.. Electro-Surgical equipment operating above 100,000 Hertz pass high currents through the body with no effect on the heart or breathing of a patient. Do you think that Murphy’s Law had anything to do with the American power line frequency being set at 60 Hertz and the frequency for the rest of the world being 50 hertz? All of the current limits referred to in the growfaq articles are based on power line frequencies of 50 or 60 hertz.
Electrocution may or may not leave physical evidence of the injury. The occurrence of burns or other skin damage is dependent upon the current density at the point where the current enters or leaves the body. Electrocutions occurring at 110 VAC seldom cause skin damage unless the point of contact is small or the victim has delicate skin. When higher voltages are involved, high currents pass through the body and there is greater likelihood that skin damage will occur. At higher voltages there are often, but not always entrance and exit wounds.
The painful truth :
This person lost the use of 3 fingers, which took over 7 months to heal.The thing that worries Overgrow / Growfaq is the fact that most people don’t understand, or believe that most of the time this beast kill’s and does so without warning.
Most Overgrow members wouldn’t want to be put into an electric chair, but will climb into one willingly while wiring a room, opening a ballast, building their own ballasts or other devices, you name it.
Electricity can and will kill you if you don’t respect it!
